The Upper Engine Gasket Set is a critical component in the engine . It is positioned between the cylinder head and engine block, forming a seal that prevents leakage of oil, coolant or combustion gases into the cylinders. The gasket is designed to withstand high temperatures and pressures generated by combustion, while also being able to adapt to any changes in temperature or pressure. The Cylinder Head Gasket must be replaced if it becomes damaged or worn out, as failure to do so can result in serious engine damage.
| 4352144(Supersedes:4955595,4025300 ) | Upper Engine Gasket Set | |
| PN | NAME | QTY |
| 3042544 | O RING SEAL | 1 |
| 3330537 | O RING SEAL | 6 |
| 3330538 | O RING SEAL | 6 |
| 3347937 | O RING SEAL | 6 |
| 3347939 | O RING SEAL | 6 |
| 3678762 | GROMMET SEAL | 1 |
| 3678770 | CONNECTION GASKET | 1 |
| 3679931(5658176) | CAMSHAFT COVER GASKET | 1 |
| 3679932(5719778) | CAMSHAFT COVER GASKET | 1 |
| 3680284 | ELECTRONIC CONTROL MODULE GASKET | 1 |
| 3680324 | FLANGE GASKET | 1 |
| 3680602 | THERMOSTAT HOUSING COVER GASKET | 1 |
| 3682177 | O RING SEAL | 1 |
| 3684336 | THERMOSTAT HOUSING GASKET | 2 |
| 4026884 | TURBOCHARGER GASKET | 1 |
| 4089255 | CAVITY PLUG | 4 |
| 4299098 | CYLINDER HEAD GASKET | 1 |
| 4299124 | O RING SEAL | 1 |
| 4299125 | O RING SEAL | 1 |
| 4907446 | EXHAUST MANIFOLD GASKET | 1 |
| 4907447 | EXHAUST MANIFOLD GASKET | 4 |
| 4907448 | EXHAUST MANIFOLD GASKET | 1 |
| 4962721 | RECTANGULAR STRIP SEAL | 1 |
| 4965689 | FUEL CONNECTION GASKET | 1 |
| 4985660 | CAMSHAFT COVER SEAL | 1 |
| 4985661 | RECTANGULAR RING SEAL | 1 |
